Lite-On 0603 Package Side View Chip LEDsThis range of LEDs, from Lite-On, are in the standard 0603 side looking package. There are a variety of colour options available and they come with a clear lens type. Dimensions: 1.6 x 0.6 mm 0603 side view package Viewing angle: 130° ### 可见光 LED,Lite-On
Lite-On 0603 Package Side View Chip s
This range of LEDs, from Lite-On, are in the standard 0603 side looking package. There are a variety of colour options available and they come with a clear lens type.
Dimensions: 1.6 x 0.6 mm
0603 side view package
Viewing angle: 130°
### 可见光 LED,Lite-On
得捷:
LED RED CLEAR SMD R/A
欧时:
Lite-On 橙红色 LED LTST-S270EKT, 4 mcd, 2.6 V, 130 °视角, 2 引脚 1608 0603 侧视 贴装
贸泽:
标准LED-SMD Red Clear 621nm
艾睿:
LED Uni-Color Red Orange 630nm 2-Pin SMD T/R
Chip1Stop:
LED Uni-Color Red Orange 630nm 2-Pin SMD T/R
Verical:
LED Uni-Color Red Orange 630nm 2-Pin SMD T/R
针脚数 2
正向电压 2 V
波长 621 nm
发光强度 5 mcd
视角 130°
透镜样式 Non-Diffused
峰值波长 630 nm
耗散功率 75 W
测试电流 20 mA
正向电流 30 mA
正向电压Max 2.6 V
正向电流Max 30 mA
工作温度Max 85 ℃
工作温度Min -55 ℃
耗散功率Max 100 mW
安装方式 Surface Mount
引脚数 2
封装公制 1608
封装 0603
长度 1.6 mm
宽度 1.15 mm
高度 0.60 mm
封装公制 1608
封装 0603
颜色 Red
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
LTST-S270EKT LiteOn 光宝 | 当前型号 | 当前型号 |
LNJ810L6DRA 松下 | 功能相似 | LTST-S270EKT和LNJ810L6DRA的区别 |
CL-270SD Citizen Electronics | 功能相似 | LTST-S270EKT和CL-270SD的区别 |
