POWER INTEGRATIONS LYT7503D LED Driver, Buck, 90VAC to 308VAC input, 1 Output, 20 kHz Switch. Frequency, SOIC-8 新
LED Driver IC 1 Output AC DC Offline Switcher Step-Down Buck Triac Dimming 8-SO
立创商城:
LYT7503D
得捷:
IC LED DRVR OFFL TRIAC 8SO
e络盟:
LED Driver, Buck, 90VAC to 308VAC input, 1 Output, 20 kHz Switch. Frequency, SOIC-8
TME:
PMIC; AC/DC switcher, LED driver; 90÷308V; Ubr:725V; SO8; 6.8Ω; 22W
Newark:
# POWER INTEGRATIONS LYT7503D LED DRIVER, BUCK, CONSTANT CURRENT, SOIC New
频率 20 kHz
输出接口数 1
针脚数 8
开关频率 20 kHz
输入电压Max 308 VAC
输入电压Min 90 VAC
输出电压Max 60 V
输出电流Max 125 mA
工作温度Max 150 ℃
工作温度Min -40 ℃
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
封装 SOIC-8
工作温度 -40℃ ~ 150℃ TJ
产品生命周期 Discontinued at Digi-Key
包装方式 Each
制造应用 -
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
