LED Drivers Power Supplies 151.2W 27-54V 2800mA 180-305Vin CC LED PS
2.8A 27 ~ 54V 恒定电流 LED 驱动器 AC DC 转换器 拓扑 1 输出
得捷:
LED DRIVER CC AC/DC 27-54V 2.8A
艾睿:
AC/DC LED Power Supply 151.2W Single 4-Pin
Jameco:
2800mA 150W Single Ouput LED Power Supply
TME:
Pwr sup.unit: switched-mode; LED; 151.2W; 27÷54VDC; 2800mA; IP67
Electro Sonic:
AC/DC LED Power Supply - Const Curr - 151.2W - Fixed: 54 Vdc @ 2,800mA - Dim: No
CDI:
LED Driver CC 150W 2800mA Linear 27-54Vdc 180-305Vac Non-PFC Non-Dimming IP67 Plastic Enclosure
额定功率 151.2 W
输出接口数 1
输出电压 27.54 VDC
输出电流 2.8 A
输出功率 151.2 W
隔离电压 3 kV
输入电压Max 305 VAC
输入电压Min 180 VAC
输出电流Max 2800 mA
输入电流Min 1.7 A
输出功率Max 151.2 W
工作温度Max 50 ℃
工作温度Min -25 ℃
电源电压 180.305VAC, 254.431VDC
输入电压 180VAC ~ 305VAC
引脚数 4
封装 Plastic Enclosure
封装 Plastic Enclosure
重量 740 g
工作温度 -25℃ ~ 50℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
