开关电源 51W 15V 3.4A
Features :
Universal AC input / Full range
Protections:Short circuit/Over load/Over voltage
Cooling by free air convection
Small and compact size
Built-in remote ON-OFF control
LED indicator for power on
100% full load burn-in test
Low profile:23mm thickness
贸泽:
开关电源 51W 15V 3.4A
艾睿:
AC/DC Power Supply Single-OUT 15V 4.1A 51W 9-Pin
Jameco:
AC to DC Power Supply Open Frame Single Output 15 Volt 4.1 Amp 51 Watt
TME:
Pwr sup.unit: switched-mode; 51W; 127÷370VDC; 90÷264VAC; 15VDC
MASTER:
AC/DC Power Supply - 1 Output - 15V@4.1A - 51W
Online Components:
AC/DC Power Supply Single-OUT 15V 4.1A 51W 9-Pin
Electro Sonic:
AC/DC Power Supply - 1 Output - 15V@4.1A - 51W
CDI:
AC/DC 50W 15V Single Output Power Supply, Open Frame
额定功率 51 W
输出接口数 1
输出电压 15 V
输出电流 4.1 A
输出功率 51 W
输出电流Max 4.1 A
输入电流Min 1.2 A
输出功率Max 51 W
电源电压 127.370VDC, 90.264VAC
输入电压 90VAC ~ 264VAC, 127VDC ~ 370VDC
安装方式 Chassis
引脚数 9
长度 7.68 in
宽度 2.17 in
高度 0.91 in
重量 240 g
工作温度 -20℃ ~ 70℃
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8504409520
