LMV321

单路低电压轨至轨输入/输出运算放大器

The , LMV358, LMV324, and LMV324S devices are single, dual, and quad low-voltage 2.7 V to 5.5 V operational amplifiers with rail-to-rail output swing. These devices are the most cost-effective solutions for applications where low-voltage operation, space saving, and low cost are needed. These amplifiers are designed specifically for low-voltage 2.7 V to 5 V operation, with performance specifications meeting or exceeding the LM358 and LM324 devices that operate from 5 V to 30 V. With package sizes down to one-half the size of the DBV SOT-23 package, these devices can be used for a variety of applications.

.

2.7-V and 5-V Performance

.

–40°C to 125°C Operation

.

Low-Power Shutdown Mode LMV324S

.

No Crossover Distortion

.

Low Supply Current

.

LMV321: 130 µA Typ

.

LMV358: 210 µA Typ

.

LMV324: 410 µA Typ

.

LMV324S: 410 µA Typ

.

Rail-to-Rail Output Swing

.

ESD Protection Exceeds JESD 22

.

2000-V Human-Body Model

.

1000-V Charged-Device Model
