MF-SM250-2

BOURNS  MF-SM250-2  自恢复保险丝, SMD 5A

保持电流IHOLDCurrent - Hold Ih| 2.5A \---|--- 跳闸电流ITRIPCurrent - Trip It| 4A 最大电压VMAXVoltage - Max| 15V 最大电流IMAXCurrent - Max| 100A 跳闸时间Time to Trip| 12S 最大耗散功率PdPower dissipation| 1.9W Description & Applications| •Compliant with AEC-Q200 Rev-C- Stress •Test Qualification for Passive Components •in Automotive Applications •Surface Mount Devices •Fully compatible with current industry standards 描述与应用| •符合AEC-Q200 Rev-C标准应力 •无源元件的测试资格 •在汽车上的应用 •表面贴装器件 •完全兼容目前的行业标准

欧时:
### MF-SM 系列与当前的工业标准完全兼容 在切断或减小跳闸电流时自动重置 依据 EIA 481-2 标准封装 ### 表面安装技术（熔丝）### 表面安装技术**可重置熔丝**用于防止电气和电子电路受到过度电流的损害。 它们可在电气过载或短路条件下快速地从低阻抗状态切换到极高阻抗状态，并可在故障消失和切断电源后自动重置并返回低阻抗状态。 使用数千个周期后仍是免维护自动重置 小型号，无需熔丝架 ### 主要应用安全系统 电源和变压器 电源开关器件 汽车和医疗设备 仪器仪表和控制 计算机和外围设备 音频视频和电讯

得捷:
PTC RESET FUSE 15V 2.5A 2SMD

立创商城:
15V 2.5A

艾睿:
Avoid constantly replacing burned out fuses with this MF-SM250-2 PTC resettable fuse from Bourns. This device has a maximum current rating of 100. This resettable fuse has a minimum operating temperature of -40 °C and a maximum of 85 °C. It has 2 terminals. Mount your resettable fuse on a printed circuit board using surface mount technology to produce the most effective results. This product is 9.5Max mm long, 3Max mm tall and 6.71Max mm deep.

Allied Electronics:
Fuse; Resettable; 0.25A; Dims 0.374x0.264x0.125"; SMT; 15VDC; DCR 0.024 Ohms; PCB

安富利:
PTC Resettable Fuse 100A 15V T/R

Chip1Stop:
PTC Resettable Fuse 2.5Ahold 5Atrip 15V 100A 1.9W 25s 0.024Ohm SMD Solder Pad 9.5 X 6.71 X 3mm T/R Automotive

Verical:
PTC Resettable Fuse 2.5Ahold 5Atrip 15V 100A 1.9W 25s 0.024Ohm SMD Solder Pad 9.5 X 6.71 X 3mm T/R Automotive

Newark:
# BOURNS  MF-SM250-2  PPTC Resettable Fuse, SMD, MF-SM Series, 2.5 A, 5 A, 15 V, -40 °C

MASTER:
PPTC Resettable Fuse - 2.5Ahold 5Atrip - 15V - 100A - 9.5 x 6.71 x 3mm - Surface Mount.

Win Source:
FUSE RESETTABLE 2.5A 15V SMD

Electro Sonic:
PPTC Resettable Fuse - 2.5Ahold 5Atrip - 15V - 100A - 9.5 x 6.71 x 3mm - Surface Mount.
