ON SEMICONDUCTOR MC74LCX373DTR2G 芯片, 透明锁存器, 八路, TSSOP-20
"s d-type low-level latch is an electronic circuit that can store state information and is used as data storage elements. With a 3-state output, this is power management at its best. This latch has a minimum operating temperature of -40 °C and a maximum of 85 °C. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. This non-inverting device has a typical operating supply voltage of 2.5|3.3 V. Its minimum operating supply voltage of 2 V, while its maximum is 3.6 V. It has 8 channels per chip.
电源电压DC 2.00V min
无卤素状态 Halogen Free
输出接口数 8
电路数 8
通道数 8
针脚数 20
位数 8
输入数 8
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2V ~ 3.6V
电源电压Max 3.6 V
电源电压Min 2 V
安装方式 Surface Mount
引脚数 20
封装 TSSOP-20
长度 6.6 mm
宽度 4.5 mm
高度 1.05 mm
封装 TSSOP-20
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
MC74LCX373DTR2G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
74LCX373MTCX 飞兆/仙童 | 完全替代 | MC74LCX373DTR2G和74LCX373MTCX的区别 |
74LCX373MTC 飞兆/仙童 | 完全替代 | MC74LCX373DTR2G和74LCX373MTC的区别 |
MC74LCX373DTG 安森美 | 完全替代 | MC74LCX373DTR2G和MC74LCX373DTG的区别 |
