功率继电器, 3PDT, 24 VDC, 10 A, MT Series, 插座, 非闭锁
* Operating Temperature: –20°C to +80°C
* Contact Rating: 6 A @ 125 VAC, 3 A @ 250 VAC
* Insulation Resistance: 1000 Megohms Min. @ 500 VDC Min. for 1 Minute
* Dielectric Strength: 1500 VAC
立创商城:
24VDC 10A 无锁存
得捷:
RELAY GEN PURPOSE 3PDT 10A 24V
贸泽:
General Purpose Relays Relays Power, Over 2 Amps - RELAY GP 3PDT 10A 24VDC LED
e络盟:
功率继电器, 3PDT, 24 VDC, 10 A, MT Series, 插座, 非闭锁
Allied Electronics:
RELAY, MULTIMODE, 24 VDC, 3 CO CONTACTS, GOLD PLATED, 11 PIN, W/ LED AND TEST BU
Chip1Stop:
Electromechanical Relay 3PDT 10A 24VDC 475Ohm Plug-In
Verical:
Electromechanical Relay 24VDC 475Ohm 10A 3PDT 35.6mm 35.5mm 57mm Plug-In Industrial Relay
MASTER:
Electromechanical Relay 24VDC 475Ohm 10A 3PDT 35.6x35.5x57mm Plug-In Industrial Relay
触点电镀 Gold
额定电压AC 400 V
额定电流 10 A
输入电压DC 24.0 V
跌落电压 2.40 V
触点额定电流 10 A
线圈电压 24 VDC
线圈电流 50.53 mA
线圈功率DC 1.20 W
线圈电阻 475 Ω
线圈功率 1.2 W
额定功率Max 2.5 KVA
安装方式 Plug In
引脚数 11
封装 -
长度 35.6 mm
宽度 35.5 mm
高度 57 mm
封装 -
触点材质 Silver Nickel
工作温度 -40℃ ~ 60℃
产品生命周期 Active
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ELV标准 Compliant
ECCN代码 EAR99
HTS代码 8536490099
