MAX398CSE+

MAXIM INTEGRATED PRODUCTS  MAX398CSE+  芯片, 模拟多路复用器, 单路, 8:1, NSOIC-16

模拟多路复用器，

Maxim Integrated 的一系列模拟多路复用器包括单个和多个开关，采用 4:1、8:1 和 16:1 配置

### 开关和多路复用器，Maxim Integrated

得捷:
IC MULTIPLEXER 8X1 16SOIC

欧时:
### 模拟多路复用器，Maxim IntegratedMaxim Integrated 的一系列模拟多路复用器包括单个和多个开关，采用 4:1、8:1 和 16:1 配置### 模拟开关，Maxim Integrated

贸泽:
Multiplexer Switch ICs 8:1 Precision Analog MUX

e络盟:
8:1 Analog Multiplexer IC, Single, 225 ohm, 3V to 15V, NSOIC-16

安富利:
The MAX398/MAX399 precision, monolithic, CMOS analog multiplexers muxes offer low on-resistance less than 100Ω, which is matched to within 6Ω between channels and remains flat over the specified analog signal range 11Ω max. They also offer low leakage over temperature NO off-leakage current less than 2.5nA at +85°C and fast switching speeds transition time less than 250ns. The MAX398 is an 8-channel device, and the MAX399 is a dual 4-channel device.The MAX398/MAX399 are fabricated with Maxim"s low-voltage silicon-gate process. Design improvements yield extremely low charge injection less than 5pC and guarantee electrostatic discharge protection ESD greater than 2000V.These muxes operate with a single +3V to +15V supply or bipolar ±3V to ±8V supplies, while retaining CMOS-logic input compatibility and fast switching. CMOS inputs provide reduced input loading. The MAX398/MAX399 are pin compatible with the industry-standard DG408, DG409, DG508A, and DG509A.

Chip1Stop:
Analog Multiplexer Single 8:1 16-Pin SOIC N

Newark:
# MAXIM INTEGRATED PRODUCTS  MAX398CSE+  8:1 Analog Multiplexer IC, Single, 225 ohm, 3V to 15V, NSOIC-16

Win Source:
IC MULTIPLEXER 8X1 16SOIC
