MB2011LS1W01

NKK SWITCHES  MB2011LS1W01  按钮开关, 非发光, SPDT, 6A, 125V

Series MB2000 miniature pushbutton switches are designed with an all metal switch action to ensure a 100,000 minimum mechanical life and a resin case to provide isolation between circuits. Although not process sealed Series MB2000 miniature pushbutton switches do have epoxy sealed terminals to prevent entry of solder flux, and other liquid agents, into the switch action.

立创商城:
MB2011LS1W01

贸泽:
按钮开关 SPDT ON-ON 6A SOLDER LUG

e络盟:
NKK SWITCHES  MB2011LS1W01  按钮开关, 非发光, SPDT, 6A, 125V

艾睿:
Manually control your circuit components with this MB2011LS1W01 push button switch from NKK Switches. It has a SPDT configuration. This device has a maximum current rating of 6 A @ 125VAC. This push switch has a minimum operating temperature of -30 °C and a maximum of 85 °C. The MB2011LS1W01 push switch has a solder lug termination style. This product is 13 mm long, 39.4 mm tall and 7.9 mm deep. The maximum AC voltage rating is 250 VAC and the maximum DC voltage rating is 30 VDC.

Allied Electronics:
SWITCH, SPDT ON ON, PLUNGER FOR SNAP

Verical:
Switch Push Button ON ON SPDT Round Plunger 6A 250VAC 30VDC Momentary Contact Panel Mount Solder Lug

Newark:
# NKK SWITCHES  MB2011LS1W01  Pushbutton Switch, SPDT, On-On, 125 V, 30 V, 6 A, Solder

Powell:
MINIATURE PUSHBUTTON/MULTI-FUNCTION
