MF-FSMF035X-2

BOURNS  MF-FSMF035X-2  自复式保险丝, PTC, 6V, 350mA, 0603

MF-FSMF 系列

应用包括 USB 端口保护、PC 主板 — 即插即用保护、移动电话 — 电池和端口保护以及 PDA/数码相机。

紧密型设计节省板空间 - 0603 印迹

小尺寸有助于非常快速地响应故障情况

薄型

### 认可

UL

欧时:
Bourns 0.35A 表面固定可复位熔断器 MF-FSMF035X-2, 6V, 1.85 x 1.05 x 0.65mm, 0.5W功耗

得捷:
PTC RESET FUSE 6V 350MA 0603

立创商城:
MF-FSMF035X-2

贸泽:
自恢复保险丝—PPTC 6volts 40amps

e络盟:
自复式保险丝, PTC, 6V, 350mA, 0603

艾睿:
An automatically resetting fuse like this MF-FSMF035X-2 PTC resettable fuse from Bourns is ideal for quickly restoring protected equipment into operation after a fuse burns out. This device has a maximum current rating of 40. This resettable fuse has a minimum operating temperature of -40 °C and a maximum of 85 °C. It has 2 terminals. Mount your resettable fuse on a printed circuit board using surface mount technology to produce the most effective results. This product is 1.85Max mm long, 0.65Max mm tall and 1.05Max mm deep.

Allied Electronics:
Fuse; Resettable; PTC; Sz 0603; 0.35A; 6VDC; DCR 0.20 Ohms @23C; SMD

安富利:
PTC Resettable Fuse 40A 6V T/R

Chip1Stop:
PTC Resettable Fuse 0.35Ahold 0.75Atrip 6V 40A 0.5W 0.1s 0.2Ohm SMD Solder Pad 0603 T/R

Verical:
PTC Resettable Fuse 0.35Ahold 0.75Atrip 6V 40A 0.5W 0.1s 0.2Ohm SMD Solder Pad 0603 T/R Automotive

Newark:
# BOURNS  MF-FSMF035X-2  PPTC Resettable Fuse, SMD, MF-FSMF Series, 350 mA, 750 mA, 6 V, -40 °C

MASTER:
PTC Resettable Fuse 0.35Ahold 0.75Atrip 6V 40A 0.5W 0.1s 0.2Ohm SMD Solder Pad 0603 T/R Automotive

Electro Sonic:
PTC Resettable Fuse 0.35Ahold 0.75Atrip 6V 40A 0.5W 0.1s 0.2Ohm SMD Solder Pad 0603 T/R Automotive

Win Source:
FUSE PTC RESET 350MA SMD 0603
