MAX7504MUA+

Serial Switch/Digital Sensor, 9Bits, 3Cel, CMOS, Square, 8Pin, Surface Mount, ROHS COMPLIANT, MO-187C-AA, MICRO MAX PACKAGE-8

* Timeout Prevents Bus Lockup MAX7500, MAX7501, MAX7502 * Hardware Reset for Added Protection * I²C Bus Interface * 3.0V to 5.5V Supply Voltage Range * 250µA typ Operating Supply Current * 3µA typ Shutdown Supply Current * ±1.5°C max Temperature Accuracy -25°C to +100°C, 3-σ * µMAX, SO Packages Save Space * Separate Open-Drain OS Output Operates as Interrupt or Comparator/Thermostat Input * Register Readback Capability * Improved LM75 Second Source

得捷:
SENSOR DIGITAL -55C-125C 8UMAX

贸泽:
Board Mount Temperature Sensors Digital Temperature Sensor

安富利:
Temp Sensor Digital Serial 2-Wire, I2C 8-Pin uMAX Tube

Chip1Stop:
Temp Sensor Digital Serial 2-Wire, I2C 8-Pin uMAX

DeviceMart:
IC TEMP SENSOR DIGIT 8-UMAX
