简洁型抗破坏开关,后面板装,与面板同一平面
An extensive range of vandal resistant security switches designed with high resistance to wear and tear, corrosion and harsh use in potentially hostile environments.
* Manufactured from Stainless Steel
* Prominent-, Domed- and Low-Profile Buttons
* Front- and Rear-Panel Mounting Options
* Front-Panel Sealing Option
贸泽:
Pushbutton Switches LOW BTN REAR MOUNT
Allied Electronics:
Switch, Pushbutton, flush; vandal resistant; rear mnt; 19mm; SPCO 5A 250V
Chip1Stop:
Switch Push Button SP Flush Round Button 5A 250VAC 28VDC Momentary Contact Solder Lug Panel Mount
Online Components:
Switch Push Button SP Flush Round Button 5A 250VAC 28VDC Momentary Contact Solder Lug Panel Mount
力源芯城:
简洁型抗破坏开关,后面板装,与面板同一平面
Electro Sonic:
Switch Push Button SP Flush Round Button 5A 250VAC 28VDC Momentary Contact Solder Lug Panel Mount
触点电镀 Silver
额定电压DC 250 V
额定电压AC 250 V
额定电流 5 A
绝缘电阻 1.00 GΩ
触点类型 SPDT
接触电阻 10.0 mΩ
触点额定电流 5.00 A
额定电压 250 VAC
额定电压DC Max 28 V
额定电压AC Max 250 V
安装方式 Through Hole
长度 35.9 mm
宽度 28.7 mm
颜色 Silver
触点材质 Fine Silver
材质 Stainless Steel
工作温度 -20℃ ~ 70℃
产品生命周期 Active
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
MP0034 Bulgin Components 布尔金原器件 | 当前型号 | 当前型号 |
MP0038 布尔金原器件 | 功能相似 | MP0034和MP0038的区别 |
