MICROCHIP MCP4018T-503E/LT 易失性数字电位器, AEC-Q100, 50 kohm, 单, I2C, 线性, ± 20%, 1.8 V
MCP4017/4018/4019 数字电位计
### 数字电位计 -
得捷:
IC DGTL POT 50KOHM 128TAP SC70-6
立创商城:
MCP4018T-503E/LT
欧时:
### MCP4017/4018/4019 数字电位计### 数字电位计 - Microchip
e络盟:
易失性数字电位器, AEC-Q100, 50 kohm, 单, I2C, 线性, ± 20%, 1.8 V
艾睿:
The MCP4018T-503E/LT digital potentiometer from Microchip Technology is easy to use for your varied resistance application. This digital potentiometer has a minimum operating temperature of -40 °C and a maximum of 125 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This device uses a single power supply.
Allied Electronics:
MCP4018T-503E/LT, Digi Potentiometer 50kOhm 128-Pos Linear Serial-I2C 6-Pin SC-70
Chip1Stop:
Digital Potentiometer 128POS 50kOhm Single Automotive 6-Pin SC-70 T/R
Verical:
Digital Potentiometer 50kOhm 128POS Volatile Linear Automotive 6-Pin SC-70 T/R
Newark:
# MICROCHIP MCP4018T-503E/LT Volatile Digital Potentiometer, 50 kohm, Single, I2C, Linear, ± 20%, 1.8 V
Online Components:
50kOhmDigital Potentiometer 128POS Volatile Automotive 6-Pin SC-70 T/R
DeviceMart:
IC DGTL POT 50K 128TAPS SC70-6
电源电压DC 1.80V min
容差 ±20 %
供电电流 0.045 mA
电路数 1
针脚数 128
电阻 50 kΩ
阻值偏差 ±20 %
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 1.8V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 1.8 V
安装方式 Surface Mount
引脚数 6
封装 SC-70-6
长度 2 mm
宽度 1.25 mm
高度 1 mm
封装 SC-70-6
工作温度 -40℃ ~ 125℃
温度系数 ±50 ppm/℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 信号处理, Automotive
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MCP4018T-503E/LT Microchip 微芯 | 当前型号 | 当前型号 |
AD5247BKSZ100-RL7 亚德诺 | 功能相似 | MCP4018T-503E/LT和AD5247BKSZ100-RL7的区别 |
AD5247BKSZ5-RL7 亚德诺 | 功能相似 | MCP4018T-503E/LT和AD5247BKSZ5-RL7的区别 |
