MCP1755ST-1802E/DB

MICROCHIP  MCP1755ST-1802E/DB  固定电压稳压器, LDO, 3.6V至16V, 300mV压差, 1.8V输出, 300mA输出, SOT-223-3

LDO Regulator Pos 1.8V 0.3A 4-Pin3+Tab SOT-223 T/R

得捷:
IC REG LIN 1.8V 300MA SOT223-3

立创商城:
MCP1755ST-1802E/DB

贸泽:
低压差稳压器 16 V,300mA low

e络盟:
固定电压稳压器, LDO, 3.6V至16V, 300mV压差, 1.8V输出, 300mA输出, SOT-223-3

艾睿:
Keep calm and stay stable by implementing this LDO MCP1755ST-1802E/DB linear regulator developed by Microchip Technology. Its typical dropout voltage at current is 0.3@300mA V. It has an overall accuracy of ±2 %. This voltage regulation device&s;s single output can produce a current up to 0.3 A. Using the part will provide the power your application needs by requiring a voltage only of 3.6 V and not exceeding a voltage of 16 V. With a fixed output that has a voltage of 1.8 V, this is power management at its best. At a load regulation of 0.1%Typ and line regulation of 0.01%/VTyp a constant current can be produced at the output of your circuit. This product will be shipped in tape and reel packaging so that components can be mounted effectively. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.5@300mA V.

Allied Electronics:
IC REG LDO 1.8V 0.3A SOT223-3

安富利:
LDO Regulator Pos 1.8V 0.3A 3-Pin SOT-223 T/R

Chip1Stop:
LDO Regulator Pos 1.8V 0.3A 4-Pin3+Tab SOT-223 T/R

TME:
Voltage stabiliser; LDO, fixed; 16V; 1.8V; 300mA; SOT223-3; SMD

Verical:
LDO Regulator Pos 1.8V 0.3A Automotive 4-Pin3+Tab SOT-223 T/R

MASTER:
LDO Regulator Pos 1.8V 0.3A 4-Pin3+Tab SOT-223 T/R

Online Components:
LDO Regulator Pos 1.8V 0.3A 4-Pin3+Tab SOT-223 T/R

Electro Sonic:
LDO Regulator Pos 1.8V 0.3A 4-Pin3+Tab SOT-223 T/R
