MMBZ5244BLT1G概述

225mW,MMBZ52xxB 系列,ON Semiconductor表面安装外壳:SOT-23 ### Zener Diodes, ON Semiconductor

齐纳 225mW,MMBZ52xxB 系列,

表面安装外壳:SOT-23

### Zener Diodes, ON Semiconductor


欧时:
ON Semiconductor MMBZ5244BLT1G 单路 齐纳二极管, 14V 5% 225 mW, 3引脚 SOT-23封装


得捷:
DIODE ZENER 14V 225MW SOT23-3


立创商城:
MMBZ5244BLT1G


艾睿:
The best way to operate a diode in the reverse-breakdown region in your circuit is by using a voltage regulator MMBZ5244BLT1G zener diode from ON Semiconductor. Its maximum power dissipation is 300 mW. Its test current is 9 mA. Its maximum leakage current is 0.1 μA. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. It is made in a single configuration. This zener device has a nominal voltage of 14 V and a voltage tolerance of 5%. This zener diode has an operating temperature range of -65 °C to 150 °C.


Allied Electronics:
MMBZ5244BLT1G Zener Diode; 14V 5% 225 mW SMT 3-Pin SOT-23


Chip1Stop:
Diode Zener Single 14V 5% 300mW Automotive 3-Pin SOT-23 T/R


Verical:
Diode Zener Single 14V 5% 300mW Automotive 3-Pin SOT-23 T/R


Newark:
# ON SEMICONDUCTOR  MMBZ5244BLT1G  Zener Single Diode, 14 V, 225 mW, SOT-23, 5 %, 3 Pins, 150 °C


Win Source:
DIODE ZENER 14V 225MW SOT23-3


MMBZ5244BLT1G中文资料参数规格
技术参数

额定电压DC 14.0 V

容差 ±5 %

额定功率 225 mW

针脚数 3

正向电压 900mV @10mA

耗散功率 225 mW

测试电流 9 mA

稳压值 14 V

正向电压Max 900mV @10mA

额定功率Max 225 mW

工作温度Max 150 ℃

工作温度Min -65 ℃

耗散功率Max 225 mW

封装参数

安装方式 Surface Mount

引脚数 3

封装 SOT-23-3

外形尺寸

长度 3.04 mm

宽度 1.4 mm

高度 0.94 mm

封装 SOT-23-3

物理参数

材质 Plastic

工作温度 -65℃ ~ 150℃

其他

产品生命周期 Active

包装方式 Tape & Reel TR

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

REACH SVHC版本 2015/12/17

海关信息

ECCN代码 EAR99

数据手册

MMBZ5244BLT1G引脚图与封装图
MMBZ5244BLT1G引脚图
MMBZ5244BLT1G封装焊盘图
在线购买MMBZ5244BLT1G
型号: MMBZ5244BLT1G
描述:225mW,MMBZ52xxB 系列,ON Semiconductor 表面安装外壳:SOT-23 ### Zener Diodes, ON Semiconductor
替代型号MMBZ5244BLT1G
型号/品牌 代替类型 替代型号对比

MMBZ5244BLT1G

ON Semiconductor 安森美

当前型号

当前型号

MMBZ5244BLT1

安森美

完全替代

MMBZ5244BLT1G和MMBZ5244BLT1的区别

MMBZ5244B-V-GS08

威世

类似代替

MMBZ5244BLT1G和MMBZ5244B-V-GS08的区别

SZMMBZ5244BLT1G

安森美

类似代替

MMBZ5244BLT1G和SZMMBZ5244BLT1G的区别
