MSP430G2433IRHB32R

混合信号微控制器 MIXED SIGNAL MICROCONTROLLER

* Low Supply-Voltage Range: 1.8 V to 3.6 V * Ultra-Low Power Consumption * Active Mode: 230 µA at 1 MHz, 2.2 V * Standby Mode: 0.5 µA * Off Mode RAM Retention: 0.1 µA * Five Power-Saving Modes * Ultra-Fast Wake-Up From Standby Mode in Less Than 1 µs * 16-Bit RISC Architecture, 62.5-ns Instruction Cycle Time * Basic Clock Module Configurations * Internal Frequencies up to 16 MHz With Four Calibrated Frequency * Internal Very-Low-Power Low-Frequency LF Oscillator * 32-kHz Crystal * External Digital Clock Source * Two 16-Bit Timer_A With Three Capture/Compare Registers * Up to 24 Capacitive-Touch Enabled I/O Pins * Universal Serial Communication Interface USCI * Enhanced UART Supporting Auto Baudrate Detection LIN * IrDA Encoder and Decoder * Synchronous SPI * I2C™ * 10-Bit 200-ksps Analog-to-Digital A/D Converter With Internal Reference, Sample-and-Hold, and Autoscan * Brownout Detector * Serial Onboard Programming, No External Programming Voltage Needed, Programmable Code Protection by Security Fuse * On-Chip Emulation Logic With Spy-Bi-Wire Interface * Package Options * TSSOP: 20 Pin, 28 Pin * PDIP: 20 Pin * QFN: 32 Pin
