MSP430F2101IRGET

混合信号微控制器 MIXED SIGNAL MICROCONTROLLER

* Low Supply Voltage Range: 1.8 V to 3.6 V * Ultra-Low Power Consumption * Active Mode: 250 µA at 1 MHz, 2.2 V * Standby Mode: 0.7 µA * Off Mode RAM Retention: 0.1 µA * Ultra-Fast Wake-Up From Standby Mode in Less Than 1 µs * 16-Bit RISC Architecture, 62.5-ns Instruction Cycle Time * Basic Clock Module Configurations * Internal Frequencies up to 16 MHz With Four Calibrated Frequencies to ±1% * 32-kHz Crystal * High-Frequency Crystal up to 16 MHz * Resonator * External Digital Clock Source * 16-Bit Timer_A With Three Capture/Compare Registers * On-Chip Comparator for Analog Signal Compare Function or Slope Analog-to-Digital A/D Conversion * Brownout Detector * Serial Onboard Programming, No External Programming Voltage Needed, Programmable Code Protection by Security Fuse * Bootstrap Loader * On Chip Emulation Module * Family Members: * MSP430F2101 * 1KB + 256B Flash Memory * 128B RAM * MSP430F2111 * 2KB + 256B Flash Memory * 128B RAM * MSP430F2121 * 4KB + 256B Flash Memory * 256B RAM * MSP430F2131 * 8KB + 256B Flash Memory * 256B RAM * Available in a 20-Pin Plastic Small-Outline Wide Body SOWB Package, 20-Pin Plastic Small-Outline Thin TSSOP Package, 20-Pin TVSOP Package, and 24-Pin QFN Package
