MC78L12ABPRPG

ON SEMICONDUCTOR  MC78L12ABPRPG  线性稳压器, 固定, 7812, 35V输入, 12V和0.1A输出, TO-92-3

The MC78L00A Series of positive voltage regulators are inexpensive, easy−to−use devices suitable for a multitude of applications that require a regulated supply of up to 100 mA. Like their higher powered MC7800 and MC78M00 Series cousins, these regulators feature internal current limiting and thermal shutdown making them remarkably rugged. No external components are required with the MC78L00 devices in many applications.

These devices offer a substantial performance advantage over the traditional zener diode−resistor combination, as output impedance and quiescent current are substantially reduced.

Features

• Wide Range of Available, Fixed Output Voltages

• Low Cost

• Internal Short Circuit Current Limiting

• Internal Thermal Overload Protection

• No External Components Required

• Complementary Negative Regulators Offered MC79L00A Series

• NCV Prefix for Automotive and Other Applications Requiring

   Unique Site and Control Change Requirements; AEC−Q100

   Qualified and PPAP Capable

• These are Pb−Free Devices
