NPN 晶体管,最大 1A,On Semiconductor### 标准带 S 或 NSV 前缀的制造商部件号具有汽车资格,符合 AEC-Q101 标准。### 双极性晶体管,On SemiconductorON Semiconductor 的各种双极晶体管,包括以下类别:小信号晶体管 功率晶体管 双晶体管 复合晶体管对 高电压晶体管 射频晶体管 双极/FET 晶体管
小信号 NPN ,
### 标准
带 S 或 NSV 前缀的制造商部件号具有汽车资格,符合 AEC-Q101 标准。
欧时:
### 通用 NPN 晶体管,最大 1A,On Semiconductor### 标准Manufacturer Part Nos with S or NSV prefix are automotive qualified to AEC-Q101 standard.### 双极性晶体管,On SemiconductorON Semiconductor 的各种双极晶体管,包括以下类别:小信号晶体管 通用晶体管 双 NPN 和 PNP 晶体管 功率晶体管 高电压晶体管 射频双极晶体管 低噪声,双匹配和复杂的双极晶体管
得捷:
TRANS 2NPN 40V 0.2A SOT363
立创商城:
MBT3904DW1T3G
艾睿:
Compared to other transistors, the NPN MBT3904DW1T3G general purpose bipolar junction transistor, developed by ON Semiconductor, can offer a high-voltage solution in your circuit. This bipolar junction transistor&s;s maximum emitter base voltage is 6 V. Its maximum power dissipation is 150 mW. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This bipolar junction transistor has an operating temperature range of -55 °C to 150 °C. It has a maximum collector emitter voltage of 40 V and a maximum emitter base voltage of 6 V.
安富利:
Trans GP BJT NPN 40V 0.2A 6-Pin SOT-363 T/R
Chip1Stop:
Trans GP BJT NPN 40V 0.2A Automotive 6-Pin SC-88 T/R
Verical:
Trans GP BJT NPN 40V 0.2A Automotive 6-Pin SC-88 T/R
Newark:
# ON SEMICONDUCTOR MBT3904DW1T3G Bipolar Transistor Array, NPN, 40 V, 150 mW, 200 mA, 100 hFE, SC-70
Win Source:
TRANS 2NPN 40V 0.2A SOT363
频率 300 MHz
额定电压DC 40.0 V
额定电流 200 mA
针脚数 6
极性 NPN
耗散功率 150 mW
击穿电压集电极-发射极 40 V
集电极最大允许电流 0.2A
最小电流放大倍数hFE 100 @10mA, 1V
额定功率Max 150 mW
直流电流增益hFE 100
工作温度Max 150 ℃
工作温度Min -55 ℃
耗散功率Max 150 mW
安装方式 Surface Mount
引脚数 6
封装 SOT-363
长度 2.2 mm
宽度 1.35 mm
高度 1 mm
封装 SOT-363
工作温度 -55℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MBT3904DW1T3G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
MBT3904DW1T1 安森美 | 完全替代 | MBT3904DW1T3G和MBT3904DW1T1的区别 |
MBT3904DW1T1G 安森美 | 类似代替 | MBT3904DW1T3G和MBT3904DW1T1G的区别 |
SMBT3904S 英飞凌 | 类似代替 | MBT3904DW1T3G和SMBT3904S的区别 |
