MSP430F1101AIRGET

混合信号微控制器 MIXED SIGNAL MICROCONTROLLER

* Low Supply Voltage Range 1.8 V 3.6 V * Ultralow-Power Consumption * Active Mode: 160 µA at 1 MHz, 2.2 V * Standby Mode: 0.7 µA * Off Mode RAM Retention: 0.1 µA * Wake-Up From Standby Mode in less than 6 µs * 16-Bit RISC Architecture, 125 ns Instruction Cycle Time * Basic Clock Module Configurations: * Various Internal Resistors * Single External Resistor * 32-kHz Crystal * High-Frequency Crystal * Resonator * External Clock Source * 16-Bit Timer_A With Three Capture/Compare Registers * On-Chip Comparator for Analog Signal Compare Function or Slope A/D Conversion * Serial Onboard Programming, No External Programming Voltage Needed Programmable Code Protection by Security Fuse * Family Members Include:   MSP430C1101: 1KB ROM, 128B RAM   MSP430C1111: 2KB ROM, 128B RAM   MSP430C1121: 4KB ROM, 256B RAM   MSP430F1101A: 1KB + 128B Flash Memory 128B RAM   MSP430F1111A: 2KB + 256B Flash Memory 128B RAM   MSP430F1121A: 4KB + 256B Flash Memory 256B RAM * Available in a 20-Pin Plastic Small-Outline Wide Body SOWB Package, 20-Pin Plastic Small-Outline Thin Package, and 20-Pin TVSOP F11x1A only and 24-Pin QFN
