ON SEMICONDUCTOR MC100LVEP14DTR2G CLOCK DRIVER, 2GHZ, TSSOP-20 新
Description
The MC100LVEP14 is a low skew 1−to−5 differential driver, designed with clock distribution in mind, accepting two clock sources into an input multiplexer. The ECL/PECL input signals can be either differential or single−ended if the VBB output is used. HSTL inputs can be used when the LVEP14 is operating under PECL conditions. The LVEP14 specifically guarantees low output−to−output skew. Optimal design, layout, and processing minimize skew within a device and from device to device.
To ensure that the tight skew specification is realized, both sides of any differential output need to be terminated identically into 50 Ω even if only one output is being used. If an output pair is unused, both outputs may be left open unterminated without affecting skew.
Features
• 100 ps Device−to−Device Skew
• 25 ps Within Device Skew
• 400 ps Typical Propagation Delay
• Maximum Frequency > 2 GHz Typical
• The 100 Series Contains Temperature Compensation
• PECL and HSTL Mode:
VCC = 2.375 V to 3.8 V with VEE = 0 V
• NECL Mode:
VCC = 0 V with VEE = −2.375 V to −3.8 V
• LVDS Input Compatible
• Open Input Default State
• These Devices are Pb−Free and are RoHS Compliant
频率 2 GHz
电源电压DC 2.38V min
无卤素状态 Halogen Free
输出接口数 5
电路数 1
针脚数 20
工作温度Max 85 ℃
工作温度Min -40 ℃
电源电压 2.375V ~ 3.8V
电源电压Max 3.8 V
电源电压Min 2.375 V
安装方式 Surface Mount
引脚数 20
封装 TSSOP-20
长度 6.6 mm
宽度 4.5 mm
高度 1.05 mm
封装 TSSOP-20
工作温度 -40℃ ~ 85℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MC100LVEP14DTR2G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
MC100LVEP14DTG 安森美 | 完全替代 | MC100LVEP14DTR2G和MC100LVEP14DTG的区别 |
MC100EP14DTG 安森美 | 类似代替 | MC100LVEP14DTR2G和MC100EP14DTG的区别 |
MC100LVEP111FARG 安森美 | 功能相似 | MC100LVEP14DTR2G和MC100LVEP111FARG的区别 |
