ON SEMICONDUCTOR MBRS240LT3G 肖特基整流器, 单, 40 V, 2 A, DO-214AA, 2 引脚, 430 mV
肖特基势垒,1A 至 2A,
### 标准
带 NSV-、SBR- 或 S- 前缀的制造商部件号符合 AEC-Q101 汽车等级。
得捷:
DIODE SCHOTTKY 40V 2A SMB
欧时:
肖特基势垒二极管,1A 至 2A,ON Semiconductor### 标准带 NSV-、SBR- 或 S- 前缀的制造商部件号符合 AEC-Q101 汽车等级。
立创商城:
MBRS240LT3G
贸泽:
Schottky Diodes & Rectifiers 2A 40V Low Vf
e络盟:
肖特基整流器, 40 V, 2 A, 单, DO-214AA, 2 引脚, 430 mV
艾睿:
If your circuit needs to adjust from an AC to DC voltage use a Schottky diode MBRS240LT3G rectifier from ON Semiconductor. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. Its peak non-repetitive surge current is 25 A, while its maximum continuous forward current is 2 A. It is made in a single configuration. This rectifier has a minimum operating temperature of -55 °C and a maximum of 125 °C.
Allied Electronics:
RECTIFIER; POWER; 0.5 V MAX. @ 25 C SUPPLY; SMB CASE 403A
安富利:
Diode Schottky 40V 2A 2-Pin SMB T/R
Chip1Stop:
Diode Schottky 40V 2A Automotive 2-Pin SMB T/R
TME:
Diode: Schottky rectifying; SMD; 40V; 2A; SMB; Package: reel, tape
Verical:
Rectifier Diode Schottky Si 40V 2A 2-Pin SMB T/R
Newark:
Schottky Rectifier, 40 V, 2 A, Single, DO-214AA, 2 Pins, 430 mV
Win Source:
DIODE SCHOTTKY 40V 2A SMB
额定电压DC 40.0 V
额定电流 2.00 A
无卤素状态 Halogen Free
输出电流 ≤2.00 A
负载电流 2 A
针脚数 2
正向电压 430mV @2A
极性 Standard
热阻 18℃/W RθJL
正向电流 2 A
最大正向浪涌电流(Ifsm) 25 A
正向电压Max 430 mV
正向电流Max 2 A
工作温度Max 150 ℃
工作温度Min -55 ℃
工作结温Max 150 ℃
安装方式 Surface Mount
引脚数 2
封装 DO-214AA
长度 4.32 mm
宽度 3.56 mm
高度 2.13 mm
封装 DO-214AA
工作温度 -55℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 安全, 电源管理, Safety, Safety, Power Management, Power Management
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2016/06/20
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MBRS240LT3G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
SS24 安森美 | 类似代替 | MBRS240LT3G和SS24的区别 |
MBRS240LT3 安森美 | 类似代替 | MBRS240LT3G和MBRS240LT3的区别 |
MBRS1540T3 安森美 | 类似代替 | MBRS240LT3G和MBRS1540T3的区别 |
