ON SEMICONDUCTOR MBRS3200T3G 肖特基整流器, 单, 200 V, 3 A, DO-214AA, 2 引脚, 860 mV
肖特基势垒,3A 至 9A,
### 标准
带 NSV-、SBR- 或 S- 前缀的制造商部件号符合 AEC-Q101 汽车等级。
得捷:
DIODE SCHOTTKY 200V 3A SMB
欧时:
### 肖特基势垒二极管,3A 至 9A,ON Semiconductor### 标准带 NSV-、SBR- 或 S- 前缀的制造商部件号符合 AEC-Q101 汽车等级。### 二极管和整流器,ON Semiconductor
立创商城:
MBRS3200T3G
e络盟:
ON SEMICONDUCTOR MBRS3200T3G. 肖特基整流二极管
艾睿:
If your circuit needs to adjust from an AC to DC voltage use a Schottky diode MBRS3200T3G rectifier from ON Semiconductor. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. Its peak non-repetitive surge current is 100 A, while its maximum continuous forward current is 3 A. It is made in a single configuration. This rectifier has an operating temperature range of -65 °C to 175 °C.
Allied Electronics:
ON Semi MBRS3200T3G; SMT Schottky Diode; 200V 4A; 2-Pin DO-214AA
安富利:
Diode Schottky 200V 3A 2-Pin SMB T/R
Chip1Stop:
Diode Schottky 200V 3A Automotive 2-Pin SMB T/R
TME:
Diode: Schottky rectifying; SMD; 200V; 3A; SMB; Package: reel, tape
Verical:
Rectifier Diode Schottky Si 200V 3A 2-Pin SMB T/R
Newark:
# ON SEMICONDUCTOR MBRS3200T3G Schottky Rectifier, 200 V, 3 A, Single, DO-214AA, 2 Pins, 860 mV
Win Source:
DIODE SCHOTTKY 200V 3A SMB
额定电压DC 200 V
额定电流 3.00 A
无卤素状态 Halogen Free
输出电流 ≤3.00 A
负载电流 3 A
针脚数 2
正向电压 840mV @3A
极性 Standard
热阻 13℃/W RθJL
正向电流 3 A
最大正向浪涌电流(Ifsm) 100 A
正向电压Max 860 mV
正向电流Max 4 A
工作温度Max 150 ℃
工作温度Min -65 ℃
安装方式 Surface Mount
引脚数 2
封装 DO-214AA
长度 4.6 mm
宽度 3.95 mm
高度 2.47 mm
封装 DO-214AA
工作温度 -65℃ ~ 175℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Power Management, 电源管理
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MBRS3200T3G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
MBRS3200T3 安森美 | 类似代替 | MBRS3200T3G和MBRS3200T3的区别 |
NRVBS3200T3G 安森美 | 功能相似 | MBRS3200T3G和NRVBS3200T3G的区别 |
