SOD-123 30V 0.5W1/2W
500 mW Zener Diodes 2.4 to 39 Volts
Features
l Planar Die construction
l 500mW Power Dissipation
l Zener Voltages from 2.4V - 39V
l Ideally Suited for Automated Assembly Processes
得捷:
DIODE ZENER 30V 500MW SOD123
立创商城:
30V ±5% 500mW
艾睿:
This MMSZ5256B-TP zener diode from Micro Commercial Components is perfect for your circuit requiring a diode to operate in the reverse-breakdown region. Its maximum power dissipation is 500 mW. Its test current is 4.2 mA. Its maximum leakage current is 0.1 μA. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This zener diode has an operating temperature range of -55 °C to 150 °C. This zener device has a nominal voltage of 30 V and a voltage tolerance of 5%. It is made in a single configuration.
Verical:
Zener Diode Single 30V 5% 49Ohm 500mW 2-Pin SOD-123 T/R
电容 13 pF
容差 ±5 %
正向电压 900 mV
耗散功率 500 mW
测试电流 4.2 mA
稳压值 30 V
正向电压Max 900mV @10mA
额定功率Max 500 mW
工作温度Max 150 ℃
工作温度Min -55 ℃
安装方式 Surface Mount
引脚数 2
封装 SOD-123
长度 2.85 mm
宽度 1.8 mm
高度 1.2 mm
封装 SOD-123
工作温度 -55℃ ~ 150℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MMSZ5256B-TP Micro Commercial Components 美微科 | 当前型号 | 当前型号 |
MMSZ5256B 威世 | 类似代替 | MMSZ5256B-TP和MMSZ5256B的区别 |
MMSZ5256B-G Sensitron Semiconductor | 类似代替 | MMSZ5256B-TP和MMSZ5256B-G的区别 |
MMSZ5256BT1G 安森美 | 功能相似 | MMSZ5256B-TP和MMSZ5256BT1G的区别 |
