MEC0252V3-000U-A99概述

MEC 系列 120 x 120 x 25 mm 24 V 2200 RPM 75 CFM 气化轴承 DC 风扇

**Features:**

* Patented MagLev Magnetic Levitate Design

* Vapo Bearing

* Low Acoustic Noise Level

* High-Temperature Endurance and Longer Life Span

* Better Oil Protection

* Better Dust-Resistance

* Higher Reliability

* Auto-Restart

**Applications:**

* Desktop PC Case, AIO, NB, UMPC, Slim PC, Mini PC, CPU Cooler, Multifunction Printer, Photo Printer, Copy Machine, Power, Game Consoler, PC Arcade Game, Gambling Machine, Audio, Conference System, Networking Phone, Refrigerator, Navigator, Vehicle Audio-Video System, IPC, LCD/LED/Plasma TV, Car Seat, Car Milometer Displayer Panel, Car Audio Amplifier, Medical PC, Testing Instrument, Cash Register

MEC0252V3-000U-A99中文资料参数规格
技术参数

工作电压 10V ~ 27.6V

额定电流 0.084 A

额定功率 2.00 W

易燃性等级 UL 94 V-0

功耗 2 W

额定电压 24 VDC

电源电压 24 VDC

外形尺寸

宽度 25.00 mm

电缆长度 330 mm

物理参数

材质 Plastic

重量 162 g

工作温度 -10℃ ~ 70℃

外壳材质 Thermoplastic

其他

产品生命周期 Active

寿命(小时) 70000h @40℃

符合标准

RoHS标准 RoHS Compliant

含铅标准 Lead Free

数据手册

在线购买MEC0252V3-000U-A99
型号: MEC0252V3-000U-A99
制造商: Sunon
描述:MEC 系列 120 x 120 x 25 mm 24 V 2200 RPM 75 CFM 气化轴承 DC 风扇
