FAIRCHILD SEMICONDUCTOR MPSA42 单晶体管 双极, NPN, 300 V, 50 MHz, 625 mW, 500 mA, 40 hFE
The from is a surface mount, NPN high voltage amplifier in SOT-23 package. This device is designed for applications as a video output and other high voltage applications.
- .
- Collector to emitter voltage Vce of 300V
- .
- Collector to emitter saturation voltage of 500mV at 20mA collector current
- .
- Power dissipation of 625mW
- .
- DC collector current of 500mA
- .
- DC current gain of 25 at Ic=1mA
- .
- Operating junction temperature range from -55°C to 150°C
频率 50 MHz
额定电压DC 300 V
额定电流 500 mA
额定功率 625 mW
针脚数 3
极性 NPN
耗散功率 625 mW
击穿电压集电极-发射极 300 V
最小电流放大倍数hFE 40 @30mA, 10V
额定功率Max 625 mW
直流电流增益hFE 40
工作温度Max 150 ℃
工作温度Min -55 ℃
耗散功率Max 625 mW
安装方式 Through Hole
引脚数 3
封装 TO-226-3
长度 5.2 mm
宽度 4.19 mm
高度 5.33 mm
封装 TO-226-3
工作温度 -55℃ ~ 150℃ TJ
产品生命周期 Active
包装方式 Bulk
制造应用 Signal Processing, Power Management, Portable Devices, Consumer Electronics, Industrial
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC标准 No SVHC
REACH SVHC版本 2015/06/15
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
MPSA42 Fairchild 飞兆/仙童 | 当前型号 | 当前型号 |
KSP42BU 飞兆/仙童 | 完全替代 | MPSA42和KSP42BU的区别 |
MPSA42_D27Z 飞兆/仙童 | 完全替代 | MPSA42和MPSA42_D27Z的区别 |
