MAX4436EUA+

运算放大器, 2个放大器, 150 MHz, 133 V/µs, 4.5V 至 5.5V, µMAX, 8 引脚

The from Products is a single-supply, 150MHz, 16bit accurate, ultra-low distortion dual op amp in 8 pin µMAX package. Dual operational amplifiers feature wide bandwidth, 16bit settling time in 23ns and low-noise/low-distortion operation. It is compensated for unity gain stability and has a small-signal -3dB bandwidth of 150MHz. The op amp requires only 15mA of supply current per amplifier while achieving 115dB open-loop gain. Voltage noise density is a low 2.2nV/√Hz and provides 97dB spurious-free dynamic range SFDR at 1MHz. It is used in high-speed 14 and 16bit ADC preamplifiers, low-noise preamplifiers, IF/RF amplifiers, low-distortion active filters, high-performance receivers and precision instrumentation.

.

Supply voltage range from 4.5V to 5.5V

.

65mA high output drive

.

Open-loop gain is 100dB VEE + 0.25 <= VOUT <= VCC -0.25, RL = 10Kohm

.

Input offset voltage is 1mV, input offset current is 1µA at TA=25°C

.

Input bias current is 14µA

.

Output current is 65mAsinking, 60mA sourcing

.

Quiescent supply current per amplifier is 15mA

.

Operating temperature range from -40°C to 85°C

.

High-Performance Receivers; High-Speed 14- and 16-Bit ADC Preamplifiers; IF/RF Amplifiers;

.

Low-Distortion Active Filters; Low-Noise Preamplifiers; Precision Instrumentation
