TEXAS INSTRUMENTS MSP430FG6626IZQWT 微控制器, 16位, 混合信号, MSP430, 20 MHz, 128 KB, 10 KB, 113 引脚, BGA
CPUXV2 series IC 16 位 20MHz 128KB(128K x 8) 闪存 113-BGA Microstar Junior(7x7)
得捷:
IC MCU 16BIT 128KB FLASH 113BGA
立创商城:
其他系列 20MHz 闪存:128K@x8bit RAM:10KB
贸泽:
16位微控制器 - MCU 25-MHz MCU with integrated dual Op Amps, 12-bit DACs, 16-bit Sigma-Delta ADC, USB, LCD, 128KB flash 113-BGA MICROSTAR JUNIOR -40 to 85
e络盟:
TEXAS INSTRUMENTS MSP430FG6626IZQWT 微控制器, 16位, 混合信号, MSP430, 20 MHz, 128 KB, 10 KB, 113 引脚, BGA
艾睿:
A microcontroller is used in modern day control systems, this MSP430FG6626IZQWT microcontroller from Texas Instruments is ideal for you. This microcontroller has a minimum operating temperature of -40 °C and a maximum of 85 °C. It has a maximum clock speed of 20 MHz. This is a 16 bit processor. This device is based on the MSP430 core architecture. Its ADC resolution is 16, while its DAC resolution is 12. This device has a typical operating supply voltage of 2.5|3.3 V. Its minimum operating supply voltage of 1.8 V, while its maximum is 3.6 V. Its flash program memory is 128KB.
安富利:
MCU 16-Bit MSP430 RISC 128KB Flash 2.5V/3.3V 113-Pin BGA MICROSTAR JUNIOR T/R
Verical:
MCU 16-bit MSP430 MSP430 RISC 128KB Flash 2.5V/3.3V Medical 113-Pin BGA MICROSTAR JUNIOR T/R
Newark:
# TEXAS INSTRUMENTS MSP430FG6626IZQWT 16 Bit Microcontroller, Mixed Signal, MSP430, 20 MHz, 128 KB, 10 KB, 113 Pins, BGA
德州仪器TI:
25 MHz MCU with 128KB Flash, 10KB SRAM, 16-bit Sigma-Delta ADC, dual DAC, DMA, 2 OpAmp, 160 seg LCD
频率 20 MHz
电源电压DC 1.80V min
针脚数 113
时钟频率 20.0 MHz
RAM大小 10 KB
位数 16
UART数量 2
模数转换数ADC 1
输入/输出数 73 Input
工作温度Max 85 ℃
工作温度Min -40 ℃
数模转换数DAC 1
电源电压Max 3.6 V
电源电压Min 1.8 V
安装方式 Surface Mount
引脚数 113
封装 BGA-113
封装 BGA-113
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/06/15
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MSP430FG6626IZQWT TI 德州仪器 | 当前型号 | 当前型号 |
MSP430FG6626IZQWR 德州仪器 | 类似代替 | MSP430FG6626IZQWT和MSP430FG6626IZQWR的区别 |
