MCU 16Bit M16C CISC 128KB Flash 3.3V/5V 100Pin LQFP
M16C/60 M16C™ M16C/60/62P Microcontroller IC 16-Bit 24MHz 128KB 128K x 8 FLASH 100-LQFP 14x14
得捷:
IC MCU 16BIT 128KB FLASH 100LQFP
艾睿:
Crucial to any electronic system is this M30620FCPGP#U7C microcontroller from Renesas, a mini computer that can be programmed to do whatever you want. This microcontroller has an operating temperature range of -40 °C to 85 °C. It has a maximum clock speed of 24 MHz. Its flash program memory is 128KB. Its ADC resolution is 10, while its DAC resolution is 8. This device has a typical operating supply voltage of 3.3|5 V. Its minimum operating supply voltage of 3 V, while its maximum is 5.5 V. This is a 16 bit processor.
Chip1Stop:
MCU 16-bit M16C CISC 128KB Flash 3.3V/5V 100-Pin LQFP
DeviceMart:
IC M16C MCU FLASH 128K 100LQFP
电源电压DC 5.00 V, 5.50 V max
时钟频率 24.0 MHz, 24.0 MHz max
RAM大小 10K x 8
位数 16
FLASH内存容量 128 KB
I/O引脚数 87
存取时间 24.0 µs
模数转换数ADC 1
工作温度Max 85 ℃
工作温度Min -40 ℃
耗散功率Max 300 mW
数模转换数DAC 1
安装方式 Surface Mount
引脚数 100
封装 LQFP-100
封装 LQFP-100
工作温度 -40℃ ~ 85℃ TA
产品生命周期 Unknown
包装方式 Tray
RoHS标准 RoHS Compliant
含铅标准 Lead Free
