MCP6034系列 5.5V 10kHz 0.9μA 高精度 运算放大器 TSSOP-14
Operational Amplifiers include single, dual or quad amplifiers in space-saving packages. These devices operate down to 1.8 V and feature rail-to-rail inputs and outputs for improved system performance and low current consumption for extended battery life 600 nA for MCP604X and 614X families. These products offer low offset V 150 μV, low bias current, high speed operation 10 MHz, high open-loop gain and other options for the embedded system designer.
立创商城:
MCP6034T-E/ST
得捷:
IC OPAMP GP 4 CIRCUIT 14TSSOP
贸泽:
Precision Amplifiers Quad 1.8V 14kHz Op Amp E temp
e络盟:
运算放大器, RRIO, 4个放大器, 10 kHz, 4 V/ms, 1.8V 至 5.5V, TSSOP, 14 引脚
艾睿:
If you need your circuit to amplify a voltage signal then this general purpose amplifier MCP6034T-E/ST OP amp from Microchip Technology is perfect for you! This op amp has a minimum operating temperature of -40 °C and a maximum of 125 °C. This device uses a single power supply. It has 4 channels per chip. This device is made with CMOS technology.
Allied Electronics:
Quad 1.8V 14kHz Op Amp, E Temp
安富利:
OP Amp Quad GP R-R I/O 5.5V 14-Pin TSSOP T/R
Chip1Stop:
OP Amp Quad GP R-R I/O 5.5V 14-Pin TSSOP T/R
Verical:
Op Amp Quad Precision Amplifier R-R I/O 5.5V Automotive 14-Pin TSSOP T/R
Win Source:
0.9 μA, High Precision Op Amps
电源电压DC 1.80V min
输出电流 ≤30 mA
供电电流 900 nA
电路数 4
通道数 4
针脚数 14
共模抑制比 70 dB
输入补偿漂移 3.00 µV/K
带宽 10 kHz
增益频宽积 10 kHz
输入补偿电压 150 µV
输入偏置电流 1 pA
工作温度Max 125 ℃
工作温度Min -40 ℃
增益带宽 10 kHz
共模抑制比Min 70 dB
电源电压 1.8V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 1.8 V
输入电压 1.5V ~ 2.1V
安装方式 Surface Mount
引脚数 14
封装 TSSOP-14
长度 5.1 mm
宽度 4.4 mm
高度 1.05 mm
封装 TSSOP-14
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MCP6034T-E/ST Microchip 微芯 | 当前型号 | 当前型号 |
MCP6074-E/SL 微芯 | 类似代替 | MCP6034T-E/ST和MCP6074-E/SL的区别 |
MCP6034-E/SL 微芯 | 类似代替 | MCP6034T-E/ST和MCP6034-E/SL的区别 |
MCP6034-E/ST 微芯 | 类似代替 | MCP6034T-E/ST和MCP6034-E/ST的区别 |
