ESD 抑制器/TVS 二极管 Bi-Directional TVS
The MSMB5.0A - MSMB170CA series of surface mount 600 watt transient voltage suppressors provide a selection of stanfoff voltage Vwm from 5.0 to 170 V. These high-reliablity devices are available in either unidirectional or bidirectional versions. The SMBG Gull-wing design in the DO-215AA package is ideal for visible solder connections. The SMBJ J-design in the DO-214AA package allows for greater PC board mounting density. It is available with SnPb or RoHS compliant matte-tin plating.
立创商城:
Vrwm:8V 600W
贸泽:
ESD 抑制器/TVS 二极管 Bi-Directional TVS
艾睿:
Prevent your circuits from experiencing malfunctions from electrostatic discharge with this MSMBJ8.0CA TVS diode from Microsemi. This device&s;s maximum clamping voltage is 13.6 V and minimum breakdown voltage is 8.89 V. Its test current is 1 mA. Its maximum leakage current is 50 μA. Its peak pulse power dissipation is 600 W. This TVS diode has a minimum operating temperature of -65 °C and a maximum of 150 °C. This product comes packaged in bulk, so the parts will be stored loosely.
Chip1Stop:
Diode TVS Single Bi-Dir 8V 600W 2-Pin SMBJ Bulk
Verical:
Diode TVS Single Bi-Dir 8V 600W 2-Pin SMBJ Bulk
