MSMLJ40A

表面安装3000瓦的瞬态电压抑制器 SURFACE MOUNT 3000 Watt Transient Voltage Suppressor

• Suppresses transients up to 3000 watts @ 10/1000 µs

• Protection from switching transients and induced RF

• Protection from ESD, and EFT per IEC 61000-4-2 and IEC 61000-4-4

• Secondary lightning protection per IEC61000-4-5 with 42 Ohms source impedance:

  -Class 1 & 2: MSML5.0A to MSML 170ACA

  -Class 3: MSML5.0A to MSML150CA

  -Class 4: MSML5.0A to MSML75CA

• Secondary lightning protection per IEC61000-4-5 with 12 Ohms source impedance:

\- Class 1: MSML5.0A to MSML170CA

\- Class 2: MSML5.0A to MSML90CA

\- Class 3: MSML5.0A to MSML48CA

\- Class 4: MSML5.0A to MSML24CA

• Secondary lightning protection per IEC61000-4-5 with 2 Ohms source impedance:

\- Class 2: MSML5.0A to MSML43CA

\- Class 3: MSML5.0A to MSML22CA

\- Class 4: MSML5.0A to MSML10CA
