1200V 60A
If you want to convert an alternating current input into a direct current, then this full bridge rectifier from is perfect for you! It is made in a single configuration. This rectifier has an operating temperature range of -40 °C to 125 °C.
艾睿:
If you want to convert an alternating current input into a direct current, then this M5060TB1200 full bridge rectifier from Crydom is perfect for you! It is made in a single configuration. This rectifier has an operating temperature range of -40 °C to 125 °C.
Allied Electronics:
DIODE MODULE; 60A; 480VAC; 800A I/P LEAKAGE
Chip1Stop:
Diode Rectifier Bridge Single 1.2KV 60A 5-Pin
Verical:
Diode Rectifier Bridge Single 1.2KV 60A 5-Pin
MASTER:
THYRISTOR MODULE - M Series Power Module
Electro Sonic:
THYRISTOR MODULE - M Series Power Module
额定电压DC 1.20 kV
额定电流 60.0 A
正向电压 1.35 V
最大反向电压(Vrrm) 1200V
正向电流 60 A
最大正向浪涌电流(Ifsm) 800 A
工作温度Max 125 ℃
工作温度Min -40 ℃
安装方式 Surface Mount
引脚数 5
封装 M50
长度 57.5 mm
高度 24.1 mm
封装 M50
工作温度 -40℃ ~ 125℃
产品生命周期 Unknown
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
HTS代码 8541100080
