Switch Rocker ON OFF ON DPDT Solder Lug 5A 250VAC 30VDC 30000Cycles
Snap-in Miniature Rocker, Solder Lug Termination, Epoxy Seal, Dielectric Strength 1500 VAC
* Two bezel sizes adapt to varied panel cutouts
* Built in protective cover shields contacts from dust
* Durable stainless housing prevents corrosion
* Isolated lamp circuit for incandescent, LED and neon lamps
Extended lamp terminal for ease of wiring and interlocking actuator prevents switch failure due to jamming or window locking. Unique stainless steel retaining clips securely hold switches over a range of panel thicknesses, even when exposed to vibration.
触点电镀 Silver
额定电压DC 30 V
接触器类型 Rocker
额定电压AC 250 V
额定电流 5 A
方向 Vertical
触点类型 DPDT
针脚数 3
额定电流Max 5A @125VAC
工作温度Max 50 ℃
工作温度Min -10 ℃
额定电压DC Max 30 V
额定电压AC Max 250 V
接触电阻Max 10 mΩ
安装方式 Lug, Panel
触点材质 Silver Alloy
工作温度 -10℃ ~ 50℃
外壳材质 Stainless Steel
包装方式 Bulk
RoHS标准 RoHS Compliant
含铅标准 Contains Lead
