MAX3227EIDB

RS-232 Line Transceivers, Single, Texas Instruments### RS-232 线路驱动器和接收器

完全版 收发器 1/1 RS232 16-SSOP

得捷:
IC TRANSCEIVER FULL 1/1 16SSOP

立创商城:
MAX3227EIDB

德州仪器TI:
3- to 5.5-V single channel 1Mbps RS-232 line driver/receiver with +/-15-kV IEC-ESD protection

欧时:
Texas Instruments MAX3227EIDB 1MBps 线路收发器, RS-232接口, 3.3 V、5 V单电源, 16引脚 SSOP封装

艾睿:
Single Transmitter/Receiver RS-232 16-Pin SSOP Tube

安富利:
The MAX3227E consists of one line driver, one line receiver, and a dual charge-pump circuit with ±15-kV IEC ESD protection pin to pin serial-port connection pins, including GND. The device meets the requirements of TIA/EIA-232-F and provides the electrical interface between an asynchronous communication controller and the serial-port connector. The charge pump and four small external capacitors allow operation from a single 3-V to 5.5-V supply. This device operates at data-signaling rates of 1 Mbit/s in normal operating mode and a maximum of 30-V/μs driver output slew rate. This device also features a logic-level output READY that asserts when the charge pump is regulating and the device is ready to begin transmitting.The MAX3227E achieves a 1-μA supply current using the auto-powerdown plus feature. This device automatically enters a low-power powerdown mode when the RS-232 cable is disconnected or the drivers of the connected peripherals are inactive for more than 30 s. They turn on again when they sense a valid transition at any driver or receiver input. Auto-powerdown saves power without changes to the existing BIOS or operating system.The MAX3227EC is characterized for operation from 0°C to 70°C. The MAX3227EI is characterized for operation from -40°C to 85°C.

Chip1Stop:
Single Transmitter/Receiver RS-232 16-Pin SSOP Tube

Verical:
Single Transmitter/Receiver RS-232 16-Pin SSOP Tube

Newark:
# TEXAS INSTRUMENTS  MAX3227EIDB  RS232 Transceiver IC, 1 Driver, 1 Mbps, 3 V to 5.5 V, SSOP-16

DeviceMart:
IC RS232 3V-5.5V DRVR 16-SSOP
