MCP6562 系列 双 1500 pA 推挽输出 比较器 - SOIC-8
This comparator circuit from Technology acts as a high gain differential amplifier to compare two input signals and generate an output signal. It has a push-pull output. This comparator has a temperature range of -40 °C to 125 °C. This device utilizes CMOS technology. Its typical PSRR is 70 dB. This device uses a single power supply. It has 2 channels per chip.
电源电压DC 1.80V min
输出电流 50 mA
电路数 1
通道数 2
针脚数 8
共模抑制比 66 dB
热阻 211 ℃/W
输入补偿电压 10 mV
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 1.8V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 1.8 V
安装方式 Surface Mount
引脚数 8
封装 MSOP-8
封装 MSOP-8
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
| 型号/品牌 | 代替类型 | 替代型号对比 |
|---|---|---|
MCP6562T-E/MS Microchip 微芯 | 当前型号 | 当前型号 |
MCP6567T-E/SN 微芯 | 完全替代 | MCP6562T-E/MS和MCP6567T-E/SN的区别 |
MCP6567T-E/MS 微芯 | 完全替代 | MCP6562T-E/MS和MCP6567T-E/MS的区别 |
MCP6567-E/SN 微芯 | 类似代替 | MCP6562T-E/MS和MCP6567-E/SN的区别 |
