MAX9077EKA+T

MAXIM INTEGRATED PRODUCTS  MAX9077EKA+T  模拟比较器, 超小型, 低功耗, 2, 580 ns, 2.1V 至 5.5V, SOT-23, 8 引脚

The is a low cost, ultra small, dual comparator in 8 pin SOT-23 package. It is optimized for 3V and 5V single supply applications. This comparator has 580ns propagation delay and consumes only 3µA per comparator. The combination of low power, single supply operation down to 2.1V and ultra small footprint makes this device ideal for battery operated applications. Unlike many comparators, there is no differential clamp between inputs allowing the differential input voltage range to extend rail to rail. Design of output stage limits supply current surges while switching minimizing power consumption under dynamic conditions. Large internal push-pull output drivers allow rail to rail output swing with loads up to 2mA making this device ideal for interface with TTL/CMOS logic. The MAX9077 is used in battery powered systems, threshold detectors/discriminators, keyless entry systems, IR receivers and digital line receivers.

.

Supply voltage range from 2.1V to 5.5V

.

Operating temperature range from -40°C to 85°C

.

Ground sensing inputs and rail to rail outputs

.

No output phase inversion for overdriven inputs

.

Power supply rejection ratio of 77dB at 2.1V

.

Input offset voltage of ±1mV

.

Input offset current of 1nA and input bias current of -5nA

.

Common mode rejection ratio CMRR of 82dB

.

All inputs and outputs tolerate a continuous short circuit fault condition to either rail
