MCP4011/4012/4013/4014 数字电位计### 数字电位计 - Microchip
MCP4011/4012/4013/4014 数字电位计
### 数字电位计 -
得捷:
IC DGTL POT 2.1KOHM 64TAP 8DFN
立创商城:
MCP4011T-202E/MC
欧时:
Microchip MCP4011T-202E/MC 2.1kΩ 64位置 数字电位计, 串行 2 线接口, 8引脚 DFN封装
贸泽:
Digital Potentiometer ICs 2.1k U/Dsingle 6-bit V POT
e络盟:
易失性数字电位器, 2.1 kohm, 单, 串行, ± 20%, 2.7 V
艾睿:
Easily trim away and fine tune resistance by adopting this MCP4011T-202E/MC digital potentiometer from Microchip Technology. This digital potentiometer has a minimum operating temperature of -40 °C and a maximum of 125 °C. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. This device uses a single power supply.
Allied Electronics:
2.1k, U/D single, 6-bit V, POT8 DFN 2x3x0.9mm T/R
安富利:
Digital Potentiometer 64POS 2.1KOhm Single 8-Pin DFN EP T/R
Chip1Stop:
Digital Potentiometer 64POS 2.1kOhm Single Automotive 8-Pin DFN EP T/R
Verical:
Digital Potentiometer 2.1kOhm 64POS Volatile Linear Automotive 8-Pin DFN EP T/R
儒卓力:
**1xDCP 50k?/64 U/D DFN8 SMD **
电源电压DC 1.80V min
容差 ±20 %
供电电流 1 µA
电路数 1
针脚数 64
电阻 2.1 kΩ
阻值偏差 ±20 %
工作温度Max 125 ℃
工作温度Min -40 ℃
电源电压 1.8V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 1.8 V
安装方式 Surface Mount
引脚数 8
封装 DFN-8
长度 3 mm
宽度 2 mm
高度 0.95 mm
封装 DFN-8
工作温度 -40℃ ~ 125℃
温度系数 ±150 ppm/℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MCP4011T-202E/MC Microchip 微芯 | 当前型号 | 当前型号 |
MCP4021T-202E/SN 微芯 | 功能相似 | MCP4011T-202E/MC和MCP4021T-202E/SN的区别 |
