MCP3021A1T-E/OT

低功耗10位A / D转换器， I2C⑩接口 Low Power 10-Bit A/D Converter With I2C⑩ Interface

* 10-bit resolution * ±1 LSB DNL, ±1 LSB INL max. * 250 µA max conversion current * 5 nA typical standby current, 1 µA max. * I2C™ compatible serial interface - 100 kHz I2C Standard mode - 400 kHz I2C Fast mode * Up to 8 devices on single 2-wire bus * 22.3 ksps in I2C Fast mode * Single-ended analog input channel * On-chip sample and hold * On-chip conversion clock * Single supply specified operation: 2.7V to 5.5V * Temperature range: - Extended: -40°C to +125°C * Small SOT-23 package

得捷:
IC ADC 10BIT SAR SOT23-5

立创商城:
MCP3021A1T-E/OT

e络盟:
模数转换器, 10 bit, 22.3 kSPS, 单端, I2C, 单, 2.7 V

艾睿:
Use this specially engineered MCP3021A1T-E/OT ADC from Microchip Technology to easily convert a time-varying analog signal to a digital number representation of the amplitude of that signal. It has a single-ended input signal. This device&s;s digital interface is serial 2-wire, spi. This device is based on SAR architecture. This ADC has a resolution of 10bit. This ADC has an input voltage of 5.3 V. This ADC has a temperature range of -40 °C to 125 °C.

Allied Electronics:
10-bit ADC, I2C, single channel5 SOT-23 T/R

安富利:
ADC Single SAR 22.3ksps 10-bit Serial 5-Pin SOT-23 T/R

Chip1Stop:
Single ADC SAR 22.3ksps 10-bit Serial 5-Pin SOT-23 T/R

TME:
A/D converter; Channels:1; 10bit; 22ksps; 2.7÷5.5V; SOT23-5

DeviceMart:
ADC 10BIT I2C INTERFACE SOT23-5
