MC78L00A 线性电压调节器,ON Semiconductor**ON Semiconductor** MC78L00A 系列为线性电压调节器,涵盖了输出为 5V MC78L05A 到 24V MC78L24A 的广泛固定输出电压。 这些正电压调节器提供热关闭和内部电流限制。 无需外部设备,它们可产生 100 mA 的输出电流。 还提供铅封装。 ### 线性电压调节器,On Semiconductor
MC78L00A 线性稳压器,
**ON Semiconductor** MC78L00A 系列为线性稳压器,涵盖了输出为 5V MC78L05A 到 24V MC78L24A 的广泛固定输出电压。
这些正稳压器提供热关闭和内部电流限制。 无需外部设备,它们可产生 100 mA 的输出电流。 还提供铅封装。
### 线性稳压器,On Semiconductor
得捷:
IC REG LINEAR 5V 100MA TO92-3
欧时:
ON Semiconductor MC78Lxx 系列 MC78L05ACPREG 线性稳压器, 最大为 30 V输入, 5 V输出, 100mA最大输出
贸泽:
线性稳压器 5V 100mA Positive
e络盟:
线性稳压器, 固定, 6.7V至30V输入, 5V/100mA输出, TO-92-3
艾睿:
If you need to maintain a steady voltage on your circuit, then this standard MC78L05ACPREG linear regulator from ON Semiconductor is perfect for you! Its typical dropout voltage at current is 1.7@40mA V. This voltage regulation device&s;s single output can produce a current up to 0.1 A. Supply your circuit with sufficient power by implementing this, which does not exceed 30 V. With a fixed output that has a voltage of 5 V, this is power management at its best. Maintain a constant voltage level with a load regulation of 60mV and line regulation of 150mV. In order to ensure safe delivery and enable quick mounting of this component after delivery, it will be encased in tape and reel packaging during shipment. Its polarity is positive. This voltage regulation device has a minimum operating temperature of 0 °C and a maximum of 125 °C.
Allied Electronics:
MC78L05ACPREG, Single Linear Voltage Regulator, 100mA 5 V, 3-Pin TO-92
安富利:
LDO Regulator Pos 5V 0.1A 3-Pin TO-92 T/R
Chip1Stop:
Standard Regulator Pos 5V 0.1A 3-Pin TO-92 T/R
Verical:
Standard Regulator Pos 5V 0.1A 3-Pin TO-92 T/R
Newark:
# ON SEMICONDUCTOR MC78L05ACPREG Linear Voltage Regulator, 7805, Fixed, 10V To 30V In, 5V And 0.1A Out, TO-92-3
力源芯城:
三端正固定电压的稳压器
DeviceMart:
IC REG LDO 5V .1A TO92
无卤素状态 Halogen Free
输出接口数 1
输入电压DC 30.0V max
输出电压 5 V
输出电流 100 mA
针脚数 3
极性 P-Channel
跌落电压 1.7V @40mA
输入电压Max 30 V
输入电压Min 10 V
输出电流Max 100 mA
工作温度Max 125 ℃
工作温度Min 0 ℃
输入电压 ≤30 V
安装方式 Through Hole
引脚数 3
封装 TO-92-3
长度 5.2 mm
宽度 4.19 mm
高度 5.33 mm
封装 TO-92-3
工作温度 0℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MC78L05ACPREG ON Semiconductor 安森美 | 当前型号 | 当前型号 |
MC78L05ACPRMG 安森美 | 类似代替 | MC78L05ACPREG和MC78L05ACPRMG的区别 |
L78L05ACZ-AP 意法半导体 | 类似代替 | MC78L05ACPREG和L78L05ACZ-AP的区别 |
LM78L05ACZ 安森美 | 类似代替 | MC78L05ACPREG和LM78L05ACZ的区别 |
