ON SEMICONDUCTOR MAX809LTRG 芯片, 监测器电路, 5.5V, SOT-23-3 新
微处理器监控和复位电路,On Semiconductor
欧时:
ON Semiconductor MAX809LTRG 处理器监控器, 1.2 至 4.9 V监控电压, 多种输出驱动, 3引脚 SOT-23封装
得捷:
IC SUPERVISOR 1 CHANNEL SOT23-3
立创商城:
Voltage Supervisor, Very Low Supply Current, 3-Pin Microprocessor, Reset Monitor
e络盟:
芯片, 监测器电路, 5.5V, SOT-23-3
艾睿:
By using this MAX809LTRG microprocessor supervisory circuit from ON Semiconductor you won&s;t have to worry if something happens to your main processor. Tape and reel packaging will encase this product during shipment, in order to ensure safe delivery and enable quick mounting of components. It has a typical reset threshold voltage of 4.63 V, with a minimum of 4.56 V and a maximum of 4.7 V. This device has a minimum operating supply voltage of 1.2 V and a maximum of 5.5 V. This part has a minimum operating temperature of -40 °C and a maximum of 105 °C.
Allied Electronics:
MAX809LTRG, Processor Supervisor 1.2 - 4.9 V, 3-Pin SOT-23
安富利:
Processor Supervisor 4.63V 1.2V to 4.9V 3-Pin SOT-23 T/R
Chip1Stop:
Processor Supervisor 4.63V 1.2V to 4.9V 3-Pin SOT-23 T/R
Verical:
Processor Supervisor 4.63V 1 Active Low/Push-Pull 3-Pin SOT-23 T/R
Newark:
# ON SEMICONDUCTOR MAX809LTRG MPU Reset Monitor, 1V-5.5V supply, 4.63V Threshold, 460 ms Delay, Active-Low Reset, SOT-23-3
DeviceMart:
IC MPU SUPERVISORY 4.63V SOT23
Win Source:
Supervisor Push-Pull, Totem Pole 1 Channel SOT-23-3 TO-236
电源电压DC 1.00V min
工作电压 1.2V ~ 5.5V
无卤素状态 Halogen Free
输出电流 20 mA
供电电流 2.5 μA
针脚数 3
阈值电压 4.63 V
复位电压Min 4.56 V
复位电压Max 4.7 V
工作温度Max 105 ℃
工作温度Min -40 ℃
电源电压 1.2V ~ 5.5V
电源电压Max 5.5 V
电源电压Min 1 V
安装方式 Surface Mount
引脚数 3
封装 SOT-23-3
长度 2.9 mm
宽度 1.3 mm
高度 0.94 mm
封装 SOT-23-3
工作温度 -40℃ ~ 105℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Computers, Powertrain, Nagivator, Instrument Cluster, Body Electronic, Occupant Protection, Battery Powered Equipment, Critical Microprocessor Power Supply Monitoring, Infotainment, Embedded Systems, Occupant Comfort, Braking
RoHS标准 RoHS Compliant
含铅标准 Lead Free
REACH SVHC版本 2015/12/17
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MAX809LTRG ON Semiconductor 安森美 | 当前型号 | 当前型号 |
CAT809LTBI-T3 安森美 | 类似代替 | MAX809LTRG和CAT809LTBI-T3的区别 |
MAX809LTR 安森美 | 类似代替 | MAX809LTRG和MAX809LTR的区别 |
TCM809SENB713 微芯 | 功能相似 | MAX809LTRG和TCM809SENB713的区别 |
