微处理器监控和复位电路,On Semiconductor### 微处理器电源电压监控和复位电路电源电压监测和监控电路,用于台式机、便携式计算机和笔记本电脑、测试和测量仪器、便携式电池供电设备和多输出电源。电源电压探测器 电源电压监控器 电源监控器 微处理器监控 微处理器电压监控器 微控制器复位电路
微处理器监控和复位电路,On Semiconductor
### 微处理器电源电压监控和复位电路
电源电压监测和监控电路,用于台式机、便携式计算机和笔记本电脑、测试和测量仪器、便携式电池供电设备和多输出电源。
电源电压探测器
电源电压监控器
电源监控器
微处理器监控
微处理器电压监控器
微控制器复位电路
得捷:
IC MPU RESET MON 4.63V SOT-323
立创商城:
Voltage Supervisor, Very Low Supply Current, 3-Pin Microprocessor, Reset Monitor
欧时:
ON Semiconductor MAX809SQ463T1G 处理器监控器, 1.2 至 4.9 V监控电压, 多种输出驱动, 3引脚 SC-70封装
贸泽:
Supervisory Circuits ANA 4.63V MC RESET
艾睿:
For additional circuit stability, add ON Semiconductor&s;s MAX809SQ463T1G microprocessor supervisory circuit, which can act as a backup processor in case the original fails, to your circuit. This component will be shipped in tape and reel packaging for effective mounting and safe delivery. It has a typical reset threshold voltage of 4.63 V, with a minimum of 4.56 V and a maximum of 4.7 V. This device has a minimum operating supply voltage of 1.2 V and a maximum of 5.5 V. This part has an operating temperature range of -40 °C to 105 °C.
Allied Electronics:
MAX809SQ463T1G, Processor Supervisor 1.2 - 4.9 V, 3-Pin SC-70
安富利:
Processor Supervisor 4.63V 1.2V to 4.9V 3-Pin SC-70 T/R
Chip1Stop:
Processor Supervisor 4.63V 1.2V to 4.9V 3-Pin SC-70 T/R
Verical:
Processor Supervisor 4.63V 1 Active Low/Push-Pull 3-Pin SC-70 T/R
Win Source:
Very Low Supply Current 3-Pin Microprocessor Reset Monitors
电源电压DC 1.00V min
无卤素状态 Halogen Free
供电电流 0.0025 mA
阈值电压 4.63 V
复位电压Min 4.56 V
复位电压Max 4.7 V
工作温度Max 105 ℃
工作温度Min -40 ℃
电源电压Max 5.5 V
电源电压Min 1 V
安装方式 Surface Mount
引脚数 3
封装 SC-70-3
长度 2.2 mm
宽度 1.35 mm
高度 0.9 mm
封装 SC-70-3
工作温度 -40℃ ~ 105℃
产品生命周期 Active
包装方式 Tape & Reel TR
制造应用 Body Electronic, Embedded Systems, Instrument Cluster, Powertrain, Infotainment, Computers, Occupant Protection, Battery Powered Equipment, Critical Microprocessor Power Supply Monitoring, Braking, Nagivator, Occupant Comfort
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MAX809SQ463T1G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
LM809M3-4.63 美国国家半导体 | 功能相似 | MAX809SQ463T1G和LM809M3-4.63的区别 |
LM809M3-4.63 NOPB 美国国家半导体 | 功能相似 | MAX809SQ463T1G和LM809M3-4.63 NOPB的区别 |
LM809M3X-4.63 NOPB 美国国家半导体 | 功能相似 | MAX809SQ463T1G和LM809M3X-4.63 NOPB的区别 |
