MCP1700 低压降电压稳压器### LDO(低压降)线性稳压器,Microchip
MCP1700 低压降电压稳压器
欧时:
Microchip MCP1700T-1202E/MB LDO 稳压器, 1.2 V输出, 250mA最大输出, 1.2 → 5 V输入, 3引脚 SOT-89封装
立创商城:
正 Vin=6V Vout=1.2V~1.2V 200mA 44dB@100Hz
得捷:
IC REG LINEAR 1.2V 200MA SOT89-3
贸泽:
低压差稳压器 250mA Adj LDO 2%
e络盟:
固定LDO稳压器, 2.3V至6V, 150mV压降, 1.2V/200mA输出, SOT-89-3
艾睿:
Use the LDO MCP1700T-1202E/MB linear regulator from Microchip Technology to maintain a constant output voltage. It has an overall accuracy of ±2 %. Its typical dropout voltage at current is 0.15@200mA V. This voltage regulation device&s;s single output can produce a current up to 0.2Min A. By only needing an input voltage of 2.3 V with a maximum of 6 V, this is the best way to control the power in your circuit. With a fixed output that has a voltage of 1.2 V, this is power management at its best. Using a load regulation of 1%Typ and line regulation of 0.75%/VTyp is needed for a programmable DC power supply. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. The maximum dropout voltage is 0.35@200mA V. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. Its polarity is positive.
Allied Electronics:
250mA CMOS LDO, Isupply 1uA and 2% VoutAccuracy3 SOT-89 T/R
安富利:
LDO Regulator Pos 1.2V 0.2A 4-Pin3+Tab SOT-89 T/R
Chip1Stop:
LDO Regulator Pos 1.2V 0.2A Automotive 4-Pin3+Tab SOT-89 T/R
TME:
Voltage regulator; LDO, fixed; 1.2V; 0.25A; SOT89; SMD; ±0.4%
Verical:
LDO Regulator Pos 1.2V 0.2A Automotive 4-Pin3+Tab SOT-89 T/R
工作电压 2.3V ~ 6V
输出接口数 1
输入电压DC 2.30V min
输出电压 1.2 V
输出电流 200 mA
针脚数 3
耗散功率 1.635 W
静态电流 4 µA
输出电容类型 Ceramic
跌落电压 0.15V @200mA
输入电压Max 6 V
输入电压Min 2.3 V
输出电压Min 1.2 V
输出电流Max 250 mA
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±2 %
输入电压 6V ~ 2.3V
安装方式 Surface Mount
引脚数 3
封装 SOT-89-3
长度 4.6 mm
宽度 2.6 mm
高度 1.6 mm
封装 SOT-89-3
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MCP1700T-1202E/MB Microchip 微芯 | 当前型号 | 当前型号 |
MCP1700T-1202E/TT 微芯 | 类似代替 | MCP1700T-1202E/MB和MCP1700T-1202E/TT的区别 |
MCP1700-1202E/TO 微芯 | 类似代替 | MCP1700T-1202E/MB和MCP1700-1202E/TO的区别 |
