MC33269DTRK-012G

800mA低压差稳压器

PMIC - 稳压器 - 线性 输出 800mA DPAK

得捷:
IC REG LINEAR 12V 800MA DPAK

立创商城:
MC33269DTRK-012G

贸泽:
LDO Voltage Regulators 12V ADJ 800mA

e络盟:
芯片, 稳压器, LDO, 固定, 12V, 0.8A, TO-252-3

艾睿:
Say goodbye to unstable voltages with this LDO MC33269DTRK-012G linear regulator from ON Semiconductor. Its typical dropout voltage at current is 1@500mA|1.1@800mA V. It has an overall accuracy of ±1 %. This voltage regulation device&s;s single output can produce a current up to 0.8Typ A. The best way to provide power to your application is by using this, which needs a voltage lower than 20 V. With a fixed output that has a voltage of 12 V, this is power management at its best. At a load regulation of 0.5% and line regulation of 0.3% your circuit is capable of maintaining a constant voltage level at your output. This product will be shipped in tape and reel packaging for quick mounting and safe delivery. This voltage regulation device has an operating temperature range of -40 °C to 125 °C. The maximum dropout voltage is 1.25@500mA|1.35@800mA V. Its polarity is positive.

安富利:
LDO Regulator Pos 12V 0.8A 3-Pin2+Tab DPAK T/R

Chip1Stop:
LDO Regulator Pos 12V 0.8A 3-Pin2+Tab DPAK T/R

Verical:
LDO Regulator Pos 12V 0.8A 3-Pin2+Tab DPAK T/R

力源芯城:
800mA低压差稳压器
