300mA低压差稳压器
PMIC - 稳压器 - 线性 正 固定 输出 300mA 8-SOIC
立创商城:
MC33275D-3.3R2G
得捷:
IC REG LINEAR 3.3V 300MA 8SOIC
贸泽:
低压差稳压器 3.3V 300mA
e络盟:
固定LDO 稳压器, 4 V至13 V输入, 260 mV压差, 3.3 V和300 mA 输出, SOIC-8
艾睿:
If you need to maintain a steady voltage on your circuit, then this LDO MC33275D-3.3R2G linear regulator from ON Semiconductor is perfect for you! Its typical dropout voltage at current is 0.025@10mA|0.115@100mA|0.22@250mA|0.26@300mA V. It has an overall accuracy of ±1 %. This voltage regulation device&s;s single output can produce a current up to 0.3 A. The best way to provide power to your application is by using this, which needs a voltage lower than 13 V. With a fixed output that has a voltage of 3.3 V, this is power management at its best. Operate at a constant current by utilizing the load regulation of 25mV and line regulation of 10mV. This component will be shipped in tape and reel packaging to allow for effective mounting and safe delivery. The maximum dropout voltage is 0.1@10mA|0.2@100mA|0.4@250mA|0.5@300mA V. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C.
安富利:
LDO Regulator Pos 3.3V 0.3A 8-Pin SOIC N T/R
Verical:
LDO Regulator Pos 3.3V 0.3A 8-Pin SOIC N T/R
力源芯城:
300mA低压差稳压器
DeviceMart:
IC REG LDO 3.3V .3A 8SOIC
Win Source:
Linear Voltage Regulator IC Positive Fixed 1 Output 3.3V 300mA 8-SOIC
输出接口数 1
输入电压DC 13.0V max
输出电压 3.3 V
输出电流 300 mA
供电电流 200 µA
针脚数 8
极性 P-Channel
静态电流 2 mA
跌落电压 0.26V @300mA
输入电压Max 13 V
输入电压Min 2.6 V
输出电压Min 3.3 V
输出电流Max 0.3 A
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±1 %
输入电压 ≤13 V
安装方式 Surface Mount
引脚数 8
封装 SOIC-8
长度 5 mm
宽度 4 mm
高度 1.5 mm
封装 SOIC-8
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MC33275D-3.3R2G ON Semiconductor 安森美 | 当前型号 | 当前型号 |
MC33275D-3.3R2 安森美 | 完全替代 | MC33275D-3.3R2G和MC33275D-3.3R2的区别 |
MC33275D-3.3 安森美 | 完全替代 | MC33275D-3.3R2G和MC33275D-3.3的区别 |
MC33275D-3.3G 安森美 | 类似代替 | MC33275D-3.3R2G和MC33275D-3.3G的区别 |
