MC78FC30HT1G

MC78FC00 系列 10 V 120 mA 表面贴装 微功耗 稳压器 -SOT-89-3

低压降 LDO 线性电压调节器，高达 120mA，

### LDO（低压降）线性稳压器，ON Semiconductor

低压降或 LDO 为线性稳压器。 我们有多种系列的线性稳压器。 LDO 稳压器可在输入 - 输出差分电压较小时运行。 LDO 稳压器可提供快速瞬态响应、宽输入电压范围、低静态电流、低噪声、高 PSRR。

欧时:
ON Semiconductor MC78FC30HT1G LDO 稳压器, 3 V输出, 80mA最大输出, ±2.5%精确度, 2 → 10 V输入, 0.9W

得捷:
IC REG LINEAR 3V 50MA SOT89-3

艾睿:
Use this LDO MC78FC30HT1G linear regulator from ON Semiconductor to vary your voltage levels to your desired level. It has an overall accuracy of ±2.5 %. Its typical dropout voltage at current is 0.5@40mA V. This device has a maximum power dissipation of 300 mW. This voltage regulation device&s;s single output can produce a current up to 0.08Typ A. With a voltage no larger than 10 V, this will supply sufficient power to your circuit. With a fixed output that has a voltage of 3 V, this is power management at its best. At a load regulation of 80mV and line regulation of 0.1mVTyp your circuit is capable of maintaining a constant voltage level at your output. Its maximum power dissipation is 300 mW. In order to guarantee safe delivery and allow for quick mounting of this component after delivery, it will be enclosed in tape and reel packaging during shipment. The maximum dropout voltage is 0.7@40mA V. This voltage regulation device has a minimum operating temperature of -30 °C and a maximum of 80 °C. Its polarity is positive.

Allied Electronics:
MC78FC30HT1G, LDO Voltage Regulator, 80mA, 3 V +/-2.5%, 2to10 Vin, 3-Pin SOT-89

富昌:
MC78FC00 系列 10 V 120 mA 表面贴装 微功耗 稳压器 -SOT-89-3

Verical:
LDO Regulator Pos 3V 0.08A 4-Pin3+Tab SOT-89 T/R

Newark:
# ON SEMICONDUCTOR  MC78FC30HT1G  Fixed LDO Voltage Regulator, 2V to 10V In, 500mV Dropout, 3V/80mA Out, SOT-89-3

DeviceMart:
IC REG LDO 3V 80MA SOT-89
