MCP1703AT-2802E/CB

LDO Regulator Pos 2.8V 0.25A Automotive 3Pin SOT-23A T/R

PMIC - 稳压器 - 线性 正 固定 1 输出 250mA SOT-23A-3

得捷:
IC REG LDO 2.8V 0.25A SOT23A-3

立创商城:
MCP1703AT-2802E/CB

艾睿:
This LDO MCP1703AT-2802E/CB linear regulator developed by Microchip Technology keeps the power stable! It has an overall accuracy of ±2 %. Its typical dropout voltage at current is 0.625@250mA V. This voltage regulation device&s;s single output can produce a current up to 0.25Min A. The best way to provide power to your application is by using this, which needs a voltage of at least 2.7 V and no higher than 16 V. With a fixed output that has a voltage of 2.8 V, this is power management at its best. Users like the load regulation of 1%Typ and line regulation of 0.1%/VTyp. This product will be shipped in tape and reel packaging to allow for quick mounting and safe delivery. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C. The maximum dropout voltage is 0.975@250mA V.

Allied Electronics:
IC REG LDO 2.8V 0.25A SOT23A-3

Verical:
LDO Regulator Pos 2.8V 0.25A Automotive 3-Pin SOT-23A T/R
