MCP1703 系列 16 V 250 mA 固定 低静态电流 LDO 稳压器-SOT-223-3
PMIC - 稳压器 - 线性 输出 250mA SOT-223-3
得捷:
IC REG LINEAR 3V 250MA SOT223-3
立创商城:
MCP1703T-3002E/DB
艾睿:
Maintain a steady voltage level with this LDO MCP1703T-3002E/DB linear regulator from Microchip Technology. It has an overall accuracy of ±2 %. Its typical dropout voltage at current is 0.625@250mA V. This voltage regulation device&s;s single output can produce a current up to 0.25Min A. Supply your circuit with sufficient power by implementing this, which requires a minimum input voltage of 2.7 V that does not exceed 16 V. With a fixed output that has a voltage of 3 V, this is power management at its best. At a load regulation of 1%Typ and line regulation of 0.1%/VTyp a constant current can be produced at the output of your circuit. Tape and reel packaging will encase the product during shipment, ensuring safe delivery and enabling quick mounting of components. The maximum dropout voltage is 0.975@250mA V. Its polarity is positive. This voltage regulation device has a minimum operating temperature of -40 °C and a maximum of 125 °C.
安富利:
LDO Regulator Pos 3V 0.25A 4-Pin3+Tab SOT-223 T/R
输出接口数 1
输入电压DC 2.70V min
输出电压 3 V
输出电流 250 mA
静态电流 2.00 µA
输出电容类型 Ceramic
跌落电压 0.625V @250mA
输入电压Max 16 V
输入电压Min 2.7 V
输出电压Min 3 V
工作温度Max 125 ℃
工作温度Min -40 ℃
精度 ±2 %
输入电压 ≤16 V
安装方式 Surface Mount
引脚数 4
封装 TO-261-4
封装 TO-261-4
工作温度 -40℃ ~ 125℃
产品生命周期 Active
包装方式 Tape & Reel TR
RoHS标准 RoHS Compliant
含铅标准 Lead Free
ECCN代码 EAR99
型号/品牌 | 代替类型 | 替代型号对比 |
---|---|---|
MCP1703T-3002E/DB Microchip 微芯 | 当前型号 | 当前型号 |
MCP1703-3002E/DB 微芯 | 完全替代 | MCP1703T-3002E/DB和MCP1703-3002E/DB的区别 |
MCP1703AT-3002E/CB 微芯 | 完全替代 | MCP1703T-3002E/DB和MCP1703AT-3002E/CB的区别 |
