MAX9722BETE+T

Audio Amp Headphone 2CH Stereo 0.13W Class-AB 16Pin TQFN EP T/R

放大器 IC 耳机，2-通道（立体声） AB 类 16-TQFN（3x3）

得捷:
IC AMP AUDIO .13W STER AB 16TQFN

安富利:
The MAX9722A/MAX9722B stereo headphone amplifiers are designed for portable equipment where board space is at a premium. The MAX9722A/MAX9722B use aunique DirectDrive® architecture to produce a ground-referenced output from a single supply, eliminating the need for large DC-blocking capacitors, which saves cost, board space, and component height. Additionally, the gain of the amplifier is set internally -2V/V, MAX9722B or adjusted externally MAX9722A. The MAX9722A/MAX9722B deliver up to 70mW per channel into a 16Ω load or 130mW into a 32Ω load and have low 0.009% THD+N. An 80dB at 217Hz power-supply rejection ratio PSRR allows these devices to operate from noisy digital supplies without an additional linear regulator. The MAX9722A/MAX9722B include ±8kV ESD protection on the headphone outputs. Comprehensive anticlick-and-pop circuitry suppresses audible clicks and pops on startup and shutdown. A low-power shutdown mode reduces the supply current to 0.1µA.The MAX9722A/MAX9722B operate from a single 2.4V to 5.5V supply, consume only 5.5mA of supply current, feature short-circuit and thermal-overload protection,and are specified over the extended -40°C to +85°C temperature range. The devices are available in tiny 16-pin thin QFN 3mm x 3mm x 0.8mm and 16-pinTSSOP packages.

Win Source:
Amplifier IC Headphones, 2-Channel Stereo Class AB 130mW x 2 @ 32 Ohm 16-TQFN 3x3
